SPICE VCF

Manual ·[]· Modulargrid

Features:

– 6HP / 195mA @ +15V / 12mA @ -12V.
– 1 input and 3 individual outputs for High Pass, Band Pass and Low Pass.
– CV inputs for Cutoff and Resonance.
– Resonance system based on the SEM VCF one. It’s capable of A controlled super round and nice resonance. With a bit of modulation this unit will make to talk your sawtooth wave.
– The XMOD potentiometer sends the BP output the CV Cutoff input adding some distortion and a variety of resonance effects to the processed sound.
